Professional DBX260 3 In 6 Out Digital Audio Processor 260 Loudspeaker Management Stage Crossover Effect Original PC Software

Audio processor

Sound processor

28-Band Graphic Equalizer

The 260 provides full bandpass and crossover configurations as well as independent output processing and a full time RTA for live

sound applications. Contractors will appreciate its control inputs for wall-panel logic control and the patent-pending Advanced

Feedback Suppression

Featues

--Feedback Elimination

--Classic Compression and Limiting

--Graphic and Parametric EQ

--Auto-EQ Function

--Full Bandpass, Crossover, and Routing Configurations

--Auto Gain Control

--Pink Noise Generator and fulltime RTA

--Setup Wizard with speaker and Power Amplifier Tunings

--Security Lockout

--Wall Panel Control Input

PA 260 Technical Specification

Number of Inputs:2) Line inputs.(1) RTA Mic input

Type:Electronically balanced/RF filtered

Maximum Input Level:>+30dBu

CMRR:> 45dB

Number of Outputs:(6) Line Outputs

Type:Electronically balanced, RF filtered

Max Output Level:+22dBu

Dynamic Range:(line) >113 dB, A-weighted, >110 dB unweighted

THD+N:0.003% typical at +4dBu, 1kHz, 0dB gain

Frequency response:20Hz – 20kHz, +/- 0.5dB

Interchannel Crosstalk: >110dB, 120dB typical, (input-to-output: >100dB)

Operating Voltage:90-130V or 220-240 VAC 50/60 Hz

Power Requirements:25 W
